Series 4 Service Videos

Series 4 Service Videos

Filter Articles By Tag

  • All
  • C-clip
  • cclip
  • e clip
  • eclip
  • footboard
  • footboard upgrade
  • Footpads
  • Heel rests
  • load wheel
  • monitor
  • recoil belt
  • recoil belt buckle
  • recoil buckle
  • seatwheel
  • Series 4
  • series4
  • Troubleshooting

Recoil Buckle Adjustment

Step 1- Feed the recoil belt through the recoil belt buckle as shown. Step 2- Feed the loose end of the recoil belt through the d-ring and feed it back on itself through the recoil buckle as shown. Once complete, you may wish to return the loose end of the recoil belt back through the ...

Series 4: Seat Load Wheel Replacement (C and E-Clip)

C-clip (Pre June 2017) Load Wheel Replacement E-clip (Post June 2017) Load Wheel Replacement

Adjusting the Push Button Footpads

Series 4: Monitor Replacement

1) Remove pin for old monitor. Please be careful of spring which will release when pin is removed. 2) Remove black washer, spring and monitor from bracket. 3) Insert new monitor through bracket on side. 4) Put new spring with zip ties on spigot tube, followed by the black washer. 5) Install R-Clip through the hole in spigot tube. ...

Adjusting the Dual-Pin Footpads

Series 4: Changing the Batteries on the S4 Monitor
